Get Users/Groups/Objects from Microsoft/Forefront Identity Manager with Azure Functions and the Lithnet Resource Management Powershell Module

Leveraging Azure Functions to query Microsoft Identity Manager

Introduction

As an Identity Management consultant if I had a $1 for every time I’ve been asked “what is user x’s current status in IDAM”, “is user x active?”, “does user x have an account in y?”, “what is user x’s primary email address?”, particularly after Go Live of an IDAM solution my holidays would be a lot more exotic.

From a Service Desk perspective IDAM implementations are often a black box in the middle of the network that for the most part do what they were designed and implemented to do. However as soon as something doesn’t look normal for a user the Service Desk are inclined to point their finger at that black box (IDAM Solution). And the “what is the current value of ..”, “does user x ..” type questions start flying.

What if we could give the Service Desk a simple query interface into FIM/MIM without needing to give them access to another complicated application?

This is the first (of potentially a series) blog post on leveraging community libraries and Azure PaaS services to provide visibility of FIM/MIM information. This first post really just introduces the concept with a working example in an easy way to understand and replicate. It is not intended for production implementation without additional security and optimisation.

Overview

The following graphic shows the concept of using Azure Functions to take requests from a client (web app, powershell, some other script) query the FIM/MIM Service and return the result. This post details the setup and configuration for the section in the yellow shaded box with the process outlined in the numbers 1, 2 & 3. This post assumes you already have your FIM/MIM implementation setup and configured according to your connected integrated applications/services such as Active Directory. In my example my connected datasource is actually Twitter.

Prerequisites

The prerequisites for this solution are;



Creating your Azure App Service

First up you’ll need to create an Azure App Service in your Azure Tenant. To keep everything logically structured for this example I created an Azure App Service in the same resource group that contains my MIM IaaS infrastructure (MIM Sync Server, MIM Service Server, SQL Server, AD Domain Controller etc).

In the Azure Marketplace select New (+) and search for Function App. Select the Function App item from the results and select Create.

Give your Azure App Service a name, choose the Resource Group where you want to locate it. Choose Dynamic for the Hosting Plan. This means you don’t have to worry about resource management for your Web App and you only pay for execution time which unless you put this into production and have gone crazy with it your costs should be zero as they will (should) be well under the free grant tier.  Put the application in the appropriate location such as close to your FIM/MIM resources that it’ll be interacting with and select Create.

Now that you have your Azure App Service setup, you need to create your Azure Function.

Create an HTTP Trigger Powershell Function App

In the Azure Portal locate your App Services Blade and select the Function App created in the steps above. Mine was named MIMMetaverseSearch in the example above. Select PowerShell as the Language and HttpTrigger-Powershell as the Function type.

Give your Function a name. I’ve kept it simple in this example and named it the same as my App Service Plan. Select Create.

Adding the Lithnet Powershell Module into your Function App.

As you’d expect the Powershell Function App by default only has a handful of core Powershell Modules. As we’re using something pretty specific we’ll need put the module into our Function App so we can load it and use the library.

Download and save the Lithnet Resource Management Powershell Module to your local machine. Something like the Powershell command below will do that.

Next follow this great blog post here from Tao to upload the Lithnet RMA PS Module you downloaded earlier into your function directory. I used WinSCP as my FTP client as I’ve shown below to upload the Lithnet RMA PS Module.

FTP to the host for your App Service and navigate to the /site/wwwroot/

Create a bin folder and upload via FTP the Lithnet RMA PS Module.

Using Kudu navigate to the path and version of the Lithnet RMA PS Module.
I’m using v1.0.6088 and my app is named MIMMetaverseSearch so MY path is D:\home\site\wwwroot\MIMMetaverseSearch\bin\LithnetRMA\1.0.6088

Note: the Lithnet RMA PS Module is 64-bit so you’ll need to configure your Web App for 64-bit as per the info in the same blog you followed to upload the module here.

Test loading the Lithnet RMA PS Module in your Function App

In your Function App select </> Develop. Remove the sample script and in your first line import the Lithnet RMA PS Module using the path from the previous step. Then, to check that it loads add a line that references a cmdlet in the module. I used Help Get-Resource. Select Save then Run.

If you’ve done everything correct when you select Run and look at the Logs you’ll see the module was loaded and the Help Get-Resource command was run in the Logs.

Allow your Function App to access your FIM/MIM Service Server

Even though you have logically placed your Function App in the same Resource Group (if you did it like I have) you’ll need to actually allow the Function App that is running in a shared PaaS environment to connect to your FIM/MIM Service Server.

Create an inbound rule in your Network Security Group to allow access to your FIM/MIM Service Server. The example below isn’t as secure as it could (and should) be as it allows access from anywhere. You should restrict the source of the request(s) accordingly. I’m just showing how to quickly get a working example. TCP Port 5725 is required to access your MIM Service Server. Enter the details as per below and select Ok.

Using an Azure Function to query FIM/MIM Service

Note: Again, this is an example to quickly show the concept. In the script below your credentials are in the script in clear text (and of course those below are not valid). For anything other than validating the concept you must protect your credentials. A great example is available here in Tao’s post.

The PS Azure Function gets the incoming request and converts it from JSON. In my request which you’ll see in the next step I’m passing in “displayName” and “objectType”.

In this example I’m using Get-Resource from the Lithnet RMA to get an object from the FIM/MIM Service. First you need to open a connection to the FIM/MIM Service Server. On my Azure IaaS MIM Service Server I’ve configured a DNS name so you can see I’m using that name in line 17 to connect to it using the unsecured credentials from earlier in the script. If you haven’t set up a DNS name for your FIM/MIM Service Server you can use the Public IP Address instead.

Line 20 queries for the ObjectType and DisplayName passed into the Function (see calling the Function in the next step) and returns the response in line 22. Again this is just an example. There is no error checking, validation or anything. I’m just introducing the concept in this post.

Testing your Function App

Now that you have the function script saved, you can test it from the Function App itself. Select Test from the options up in the right from your function. Change the Request Body for what the Function is expecting. In my case displayname and objectType. Select Run and in the Logs if you’ve got everything configured correctly (like inbound network rules, DNS name, your FIM/MIM Service Server is online, your query is for a valid resource) you should see an object returned.

Calling the Function App from a Client

Now that we have our Function App all setup and configured (and tested in the Function App) let’s send a request to the Azure Function using the Powershell Invoke-RestMethod function. The following call I did from my laptop. It is important to note that there is no authN in this example and the function app will be using whatever credentials you gave it to execute the request. In a deployed solution you’ll need to scope who can make the requests, limit on the inbound network rules who can submit requests and of course further protect the account credentials used to connect to your FIM/MIM Service Server.

Successful Response

The following screenshot shows calling the Function App and getting the responding object. Success. In a couple of lines I created a hashtable for the request, converted it to JSON and submitted it and got a response. How powerful is that!?

Summary

Using the awesome Lithnet Resource Management PowerShell Module with Azure Functions it is pretty quick and flexible to access a wealth of information we may want to expose for business benefit.

Now if only there was an affiliation program for Azure Functions that could deposit funds for each IDAM request to an Azure Functions App into my holiday fund.

Stay tuned for more posts on taking this concept to the next level.

Follow Darren on Twitter @darrenjrobinson

How to assign and remove user Office365 licenses using the AzureADPreview Powershell Module

A couple of months ago the AzureADPreview module was released. The first cmdlet that I experimented with was Set-AzureADUserLicense. And it didn’t work, there was no working examples and I gave up and used GraphAPI instead.

Since then the AzureADPreview has gone through a number of revisions and I’ve been messing around a little with each update. The Set-AzureADUserLicense cmdlet has been my litmus test. Now that I have both removing and assigning Office 365 licenses working I’ll save others the pain of working it out and give a couple of working examples.



If like me you have been experimenting with the AzureADPreview module you’ll need to force the install of the newest one. And for whatever reason I was getting an error informing me that it wasn’t signed. As I’m messing around in my dev sandpit I skipped the publisher check.
Install-Module -Name AzureADPreview -MinimumVersion 2.0.0.7 -Force -SkipPublisherCheck
Import-Module AzureADPreview RequiredVersion 2.0.0.7

Removing an Office 365 License from a User

Removing a license with Set-AzureADUserLicense looks something like this.

What if there are multiple licenses ? Similar concept but just looping through each one to remove.

Assigning an Office 365 License to a User

Now that we have the removal of licenses sorted, how about adding licenses ?

Assigning a license with Set-AzureADUserLicense looks something like this;

Moving forward this AzureAD Powershell Module will replace the older MSOL Module as I wrote about here. If you’re writing new scripts it’s a good time to start using the new modules.

Follow Darren on Twitter @darrenjrobinson



Office365 Licensing Management Agent for Microsoft Identity Manager

Licensing for Office365 has always been a moving target for enterprise customers. Over the years I’ve implemented a plethora of solutions to keep licensing consistent with entitlement logic. For some customers this is as simple as everyone gets say, an E3 license. For other institutions there are often a mix of ‘E’ and ‘K’ licenses depending on EmployeeType.

Using the Granfeldt PowerShell Management Agent to import Office365 Licensing info

In this blog post I detail how I’m using Søren Granfeldt’s extremely versatile PowerShell Management Agent yet again. This time to import Office365 licensing information into Microsoft Identity Manager.

I’m bringing in the licenses associated with users as attributes on the user account. I’m also bringing in the licenses from the tenant as their own ObjectType into the Metaverse. This includes the information about each license such as how many licenses have been purchased, how many licenses have been issued etc.

Overview

I’m not showing assigning licenses. In the schema I have included the LicensesToAdd and LicensesToRemove attributes. Check out my Adding/Removing User Office365 Licences using PowerShell and the Azure AD Graph RestAPI post to see how to assign and remove licenses using Powershell. From that you can workout your logic to implement an Export flow to manage Office365 licenses.

Getting Started with the Granfeldt PowerShell Management Agent

If you don’t already have it, what are you waiting for. Go get it from here. Søren’s documentation is pretty good but does assume you have a working knowledge of FIM/MIM and this blog post is no different.

Three items I had to work out that I’ll save you the pain of are;

  • You must have a Password.ps1 file. Even though we’re not doing password management on this MA, the PS MA configuration requires a file for this field. The .ps1 doesn’t need to have any logic/script inside it. It just needs to be present
  • The credentials you give the MA to run this MA are the credentials for the account that has permissions to the Office365 Tenant. Just a normal account is enough to enumerate it, but you’ll need additional permissions to assign/remove licenses.
  • The path to the scripts in the PS MA Config must not contain spaces and be in old-skool 8.3 format. I’ve chosen to store my scripts in an appropriately named subdirectory under the MIM Extensions directory. Tip: from a command shell use dir /x to get the 8.3 directory format name. Mine looks like C:\PROGRA~1\MICROS~2\2010\SYNCHR~1\EXTENS~2\O365Li~1

Schema.ps1

My Schema is based around the core Office365 Licenses function. You’ll need to create a number of corresponding attributes in the Metaverse Schema on the Person ObjectType to flow the attributes into. You will also need to create a new ObjectType in the Metaverse for the O365 Licenses. I named mine LicensePlans. Use the Schema info below for the attributes that will be imported and the attribute object types to make sure what you create in the Metaverse aligns, so you can import the values. Note the attributes that are multi-valued.

Import.ps1

The logic which the Import.ps1 implements I’m not going to document here as this post goes into all the details Enumerating all Users/Groups/Contacts in an Azure tenant using PowerShell and the Azure Graph API ‘odata.nextLink’ paging function

Password Script (password.ps1)

Empty as not implemented

Export.ps1

Empty as not implemented

Management Agent Configuration

As per the tips above, the format for the script paths must be without spaces etc. I’m using 8.3 format and I’m using an Office 365 account to connect to Office365 and import the user and license data.



As per the Schema script earlier in this post I’m bringing user licensing metadata as well as the Office365 Tenant Licenses info.


Attributes to bring through aligned with what is specified in the Schema file.


Flow through the attributes to the attributes I created in the Metaverse on the Person ObjectType and to the new ObjectType LicensePlans.


Wiring it up

To finish it up you’ll need to do the usual tasks of creating run profiles, staging the connector space from Office365 and importing into the Metaverse.

Enjoy.

Follow Darren on Twitter @darrenjrobinson

Getting Users, Groups & Contacts via the Azure Graph API using Differential Query & PowerShell

This is the final post in a series detailing using PowerShell to leverage the Azure AD Graph API. For those catching up it started here introducing using PowerShell to access the Azure AD via the Graph API, licensing users in Azure AD via Powershell and the Graph API, and returning all objects using paging via Powershell and the Graph API.

In this post I show how to;

  • enumerate objects from Azure AD via Powershell and the Graph API, and set a delta change cookie
  • enumerate changes in Azure AD since the last query
  • return objects that have changed since the last query
  • return just the changed attributes on objects that have changed since the last query
  • get a differential sync from now delta change link

Searching through MSDN and other resources working this out I somehow stumbled upon a reference to changes in the API that detail the search filters. v1.5 and later of the API requires filters using the context ‘Microsoft.DirectoryServices.User|Group|Contact’ etc instead of ‘Microsoft.WindowsAzure.ActiveDirectory.User|Group|Contact’ which you’ll find in the few examples around. If you don’t want to return all these object types update the filter on line 21 in the script below.

Here is the script to return all Users, Groups and Contacts from the tenant along with all the other options I detail in this post. Update the following for your tenant;

  • line 6 for your tenant URI
  • line 10 for your account in the tenant
  • line 11 for the password associated with your account from line 10

Here is a sample output showing the Users, Groups, Contacts and DirectoryLinkChange objects. Note: if you have a large tenant that has been in place for a period of time it may take a while to enumerate.  In this instance you can use the Differential Sync from now option. More on that later.

Running the query again using the Differential DeltaLink from the first run now returns no results. This is as expected as no changes have been made in the tenant on the objects in our query.

Now if I make a change in the tenant and run the query again using the Differential DeltaLink I get 1 result. And I get the full object.

What if I just wanted to know the change that was made?

If we add ‘&ocp-aad-dq-include-only-changed-properties=true’ to the URI that’s exactly what we get. The object and what changed. In my case the Department attribute.

Finally as alluded to earlier there is the Differential Sync from now option. Very useful on large tenants where you can query and get all users, contacts, groups etc without using differential sync, then get the Differential Delta token for future sync queries. So I’ve used the same URI that I used as the beginning of this blog post but in the header specified ‘ocp-aad-dq-include-only-delta-token’ = “true” and as you can see I returned no results but I got the important Differential Query DeltaLink.

Summary

Using Powershell we can leverage the Azure AD Graph RestAPI and use the Differential Sync functions to efficiently query Azure AD for changes rather than needing to enumerate an entire tenant each time. Brilliant.

Follow Darren on Twitter @darrenjrobinson

Enumerating all Users/Groups/Contacts in an Azure tenant using PowerShell and the Azure Graph API ‘odata.nextLink’ paging function

Recently I posted about using PowerShell and the Azure Active Directory Authentication Library to connect to Azure AD here. Whilst that post detailed performing simple tasks like updating an attribute on a user, in this post I’ll use the same method to connect to Azure AD via PowerShell but cover;

  • enumerate users, contacts or groups
  • where the number of objects is greater than the maximum results per page, get all remaining pages of results
  • limit results based on filters

The premise of my script was one that could just be executed without prompts. As such the script contains the ‘username’ and ‘password’ that are used to perform the query. No special access is required for this script. Any standard user account will have ‘read’ permissions to Azure AD and will return results.

Here is the base script to return all objects of a given type from a tenant. For your environment;

  • change line 7 for your tenant name
  • change line 11 for your account in your tenant
  • change line 12 for the password associated with the account specified in line 11
  • change line 18 for the object type (eg. Users, Groups, Contacts)

I’ve hardcoded the number of results to return per page in both line 39 and 64 to the maximum 999. The default is 100. I wanted to return all objects as quickly as possible.

The first query along with returning 999 query results also returns a value for $query.’odata.nextLink’ if there are more than 999 results. The .nextLink value we then use in subsequent API calls to return the remaining pages until we have returned all objects.

Brilliant. So we can now simply change line 18 for different object types (Users, Groups, Contacts) if required. But what if we want to filter on other criteria such as attribute values?

Here is a slightly modified version (to the URI) to include a query filter. Lines 19-24 have a couple of examples of query filters.

So there you have the basics on getting started returning large numbers of objects from Azure AD via Azure Graph from PowerShell. Hopefully the time I spent working out the syntax for the URI’s helps someone else out as there aren’t any examples I could find whilst working this out.

Follow Darren on Twitter @darrenjrobinson

Simple reporting from the FIM/MIM Metaverse to PowerBI using the Lithnet FIM/MIM Sync Service PowerShell Module

I have a customer that is looking to report on FIM/MIM identity information. The reports they are looking for aren’t overly complex and don’t necessarily justify the need the full FIM/MIM reporting infrastructure. So I spent a few hours over a couple of days looking at alternatives. In this blog post I give an overview of using the awesome Lithnet FIM/MIM Sync Service PowerShell Module recently released from Ryan Newington to do basic reporting on the Microsoft (Forefront) Identity Manager Metaverse into PowerBI.

I’ll briefly show how to leverage the Lithnet FIM/MIM Sync Service PowerShell Module to extract Person objects and their metadata (based on a search filter criteria) from the MIM/FIM Metaverse and output to a file for PowerBI.

I cover;

  • Building a query
  • Executing the query
  • Filtering the results for output to a file (CSV)
  • Importing to PowerBI as a dataset, creating a report showing results in a Dashboard

First up you’ll need to download and install the module from https://github.com/lithnet/miis-powershell

Using the FIM/MIM Sync Service PowerShell Module to query the Metaverse

What operators you can choose on your attribute types (boolean, string, integer, reference etc) in the Metaverse Search function in the Synchronisation Service Manager you can also perform using the Lithnet FIM/MIM Sync Service PowerShell Module.

By creating a search with multiple criteria in the Metaverse Search you can filter the results from the Metaverse.


As shown below you can see that we get 302 results.


So let’s import the Lithnet FIM/MIM Sync Service PowerShell Module, create a filter execute it and look at the results. As you’d expect we get the same result. Excellent.


Remember that using this PowerShell automation module, the backend is still the WMI interface behind the Synchronisation Service Manager. This means you can’t for example create a query filter using “greater than/less than” if you can’t do it in the UI.

Take my Twitter FriendsCount attribute of type Number/Integer as an example.


I can’t create a query filter that would return results where FriendsCount > 20,000. I can only use the IsPresent, IsNotPresent and Equals.


On a sidenote the PowerShell error message will give you a hint at what operators you can use as shown below.


However, if you try and use StartsWith for an Integer attribute the search will execute but just return no results. My tip then is define your query in the Metaverse Search GUI and when you get what results you want/expect, create the equivalent query in PowerShell and validate you get the same number of results.

Final note on query filters. Multiple criteria are an AND operation filter, NOT OR.


Let’s do something with the results

Now that we have a query sorted let’s do something with the results. The result set is the full attribute list and values for each associated object that matched our query from the Metaverse. That’s way more info than what I and probably you need as well. So iterate through the results, pull out the attribute values that we want to do something with and export them as a CSV file.


What to do with the output ?

For this overview I’ve just chosen the local file (CSV) that I exported as part of the script as the input dataset in PowerBI. https://app.powerbi.com

On the right hand side I’ve chosen the columns that were exported to the CSV and they appear in the main window.


Click Pin to Live Page. You’ll be prompted to save the report first so do that then I choose New Dashboard for the report. Click Pin live.


I can then refine and get some visual reports quickly using text based queries using keywords from the dataset columns. Like Top 10 by number of friends from the dataset.


Create a couple of queries and pin them to the Dashboard and the data comes to life.


Summary

The Lithnet FIM/MIM Sync Service PowerShell Module provides a really easy way to expose information from the Metaverse that may satisfy many reporting and other requirements. Taking the concept further it wouldn’t be too complex to export the data to an Azure SQL DB on a schedule and have the results dynamically update on a PowerBI Dashboard.
The concept of exporting data for reporting is just one practical example using the tools. Huge thanks to Ryan for creating the Lithnet tools and publishing to the community. Keep in mind the tools disclaimer too.

Here is the sample PowerShell.

Follow Darren on Twitter @darrenjrobinson



Goodbye Set-MsolUser, Hello Set-AzureADUser & Azure Graph API

Update: April 13 2017.
See this post for adapting to changes in the AzureAD
PowerShell Module Helper Libraries

Recently Microsoft released the preview of the v2.0 Azure AD PowerShell cmdlets. https://azure.microsoft.com/en-us/updates/azure-ad-new-powershell-cmdlets-preview/

I’ve got a project coming up where I’m looking to change my approach for managing users in Azure using Microsoft Identity Manager. Good timing to do a quick proof of concept to manage users with the new cmdlets and directly using the Graph API in preparation to move away from the msol cmdlets.

New Modules

First up, the Azure AD v2.0 PowerShell module was released in public preview on July 13, 2016. There will likely be changes before they become GA, so keep that in mind.

The v2.0 Azure AD PowerShell Module modules themselves are available for download from here https://www.powershellgallery.com/packages/AzureADPreview/1.1.143.0

If you have Windows Management Framework v5 installed you can download and install from PowerShell (as below).

Once installed, pretty quickly you can import the module, authenticate to your tenant, retrieve a user and update a few attributes (as below).

Whilst functional it doesn’t really work for how we need to interact with Azure from an Identity Management perspective. So how can we still use PowerShell but enumerate and manipulate identities in Azure ?

Now that we have the AzureAD v2.0 module installed we can reference the Active Directory library it installs (Microsoft.IdentityModel.Clients.ActiveDirectory.dll), authenticate to our Tenant retrieve users, and update them. That’s exactly what is shown in the commands below.

Where interacting with the GraphAPI directly really shines however is at the directory services layer and the Differential Query functionality.  https://msdn.microsoft.com/en-us/Library/Azure/Ad/Graph/howto/azure-ad-graph-api-differential-query

As such this is the approach that I’ll be taking for integration of Azure with Microsoft Identity Manager for managing users for entitlements (such as Azure licensing).
I hope this though also saves a few people time in working out how to use PowerShell to manage Azure objects via the Graph API (using both the PowerShell Module or via the RestAPI).

Exception from HRESULT 0x80230729 creating a new FIM/MIM Management Agent

Another day, another piece of FIM/MIM experimentation. I had built a fresh MIM 2016 environment in Azure to test a few scenarios out. That all went quick and seamlessly thanks to some great templates and a few scripts. Until I came to create the management agent (the purpose of today’s experimentation).

It didn’t matter if I tried to Create a New Management Agent or Import the Management Agent. I just got “Exception from HRESULT 0x80230729”. The common element however was that the Management Agent I was creating was based off a 3rd party MA based on Microsoft’s Extensible Connectivity Management Agent (ECMA). Specifically I was using Soren Granfeldts PowerShell MA.

HResult 0x80230729

Now I’ve used this MA extensively and not had a problem previously.

So I retraced my steps, clean build, pre-requisites etc. All good. I then tried creating an MA from the out of the box connectors. That worked. I successfully created an Active Directory Management Agent.

In the Windows Application Log I found the following from when I was trying to create the PSMA. A little more to go on from that information.

AppLog

The link in the error message provides some info https://msdn.microsoft.com/en-us/library/dd409252(VS.100).aspx but it is a generic .NET article. Having experience with MIIS/ILM/FIM/MIM I figured the SyncEngine WebServices Config file would be appropriate place for the information provided in the MSDN link to go.

The Fix

The miiserver.exe.config file located in the default installation directory C:\Program Files\Microsoft Forefront Identity Manager\2010\Synchronization Service\Bin is what you need to edit.

Near the end of the misserver.exe.config file find the <runtime> section. Insert the line <loadFromRemoteSources enabled=”true”/> as shown below.

RemoteSources

Restart the Forefront Identity Manger Server Service from the Services Control Panel and you’re back in action.

Management Agent created and back to the task at hand. Happy days.

MACreated

Follow Darren on Twitter @darrenjrobinson

Consuming CSV files from an Exchange Mailbox via Exchange Web Services and FIM/MIM 2016 using the Granfeldt PowerShell MA

This solution on first look is quite random. A management agent that consumes a flat file (comma separated file) isn’t ground breaking, but when the twist is that the CSV file is in an email in an Exchange Inbox, it’s quite a different scenario.

Background

My customer uses a Cloud Service for their recruitment processes. The cloud service does have a SOAP API that I could potentially develop a FIM/MIM solution for using the Microsoft Web Services Management Agent, however my customer does not have API access to their tenant, the vendor isn’t overly responsive and I need a solution in days not weeks.

On the upside, my customer can quickly create reports in the SaaS Portal, and schedule them to be delivered (via CSV/Excel) to an email address. So, what if I was able to integrate FIM/MIM to the inbox that receives the emails with attached reports that contain the information I require and process it accordingly? This blog post is that solution.

Overview

Once a day there is a scheduled process that generates a report (CSV) of new staff from a SaaS provider. That CSV is emailed to an Inbox we created to receive these reports. Using the Granfeldt PowerShell Management Agent I created a solution that;

  • Connects to the specified Exchange Mailbox using Exchange Web Services
    • Enumerates the inbox looking for emails with attachments
    • Validates the emails with attachments by looking for the sender and attachment type we are expecting
    • Extracts the attachment to a file share
    • Moves all messages with attachments to a Processed subfolder
  • Processes the most recent report attachment (CSV) (in case the MA hasn’t run for few days or the reports start coming more than once a day) or if there is no new email message with attachment in the inbox, processes the most recent attachment we previously put in the file share
    • Each report is cumulative so the MA logic stays simple
  • Imports to MIM the new staff that are due to start in the next 7 days (to allow for all access to be setup prior to their first day of employment) and kicks off the MIM Provisioning processes
    • Triggers entitlements and access through the system accordingly (not covered in this post, but includes provisioning of mailbox, home directory, group memberships etc)

Notes:

  • The MIM Synchronisation Service Account will need access permissions to save files into the File Share
  • The MIM Server and this PSMA will require the Microsoft EWS 2.2 API to be installed on the MIM Synchronisation Server. It is available from here https://www.microsoft.com/en-us/download/details.aspx?id=42951

Getting Started with the Granfeldt PowerShell Management Agent

First up, you can get it from here. Søren’s documentation is pretty good but does assume you have a working knowledge of FIM/MIM and this blog post is no different.

Three items I had to work out that I’ll save you the pain of are;

  • You must have a Password.ps1 and Export.ps1 file. Even though we’re not doing password management, or exporting back to the SaaS Provider on this MA, the PS MA configuration requires a file for these fields. The .ps1 doesn’t need to have any logic/script inside it. It just needs to be present.
  • The credentials you give the MA to run the scripts as, needs to be in the format of just ‘accountname’ NOT ‘domain\accountname’. I’m using the AD Account associated with the Exchange Mailbox that receives the emails with the CSV reports.
  • The path to the scripts in the PS MA Config must not contain spaces and be in old-skool 8.3 format. I’ve chosen to store my scripts in an appropriately named subdirectory under the MIM Extensions directory. Tip: from a command shell use dir /x to get the 8.3 directory format name. Mine looks like C:\PROGRA~1\MICROS~4\2010\SYNCHR~1\EXTENS~2\PageUp

Schema.ps1

My schema is essentially the columns that are in the CSV report that I’m importing.

Password Script (password.ps1)

Empty as described above

Import.ps1

Connect to the Exchange Mailbox, find messages from the defined user sending them where the attachment is of the expected naming and format. Extract the CSV file to a File Share. Move emails with attachments to a processed folder. Parse the CSV, perform some logic on the data and import objects and values for new employees.

Export.ps1

Empty as we’re not writing anything back to the SaaS provider.

Wiring it all together

In order to wire the functionality all together there are the usual number of configuration steps to be completed. Below I’ve shown a number of the key points associated with making it all work. This is all Synchronisation Engine MA configuration tasks. Basically create the PS MA, import attributes from the PS MA, create your MA Run Profiles and let it loose.

Management Agent Configuration

As per the tips above, the format for the script paths must be without spaces etc. I’m using 8.3 format and I’m using the same service account as my AD MA.

Password and Export scripts must be specified but as we’re not doing password management or exporting they’re empty as detailed above.

If your schema.ps1 file is formatted correctly, you can select your attributes/columns that will be coming in from the CSV file.

My join rule is simple. StaffID to AccountName in the MetaVerse.

My import flows are direct flows with a Boolean flag to kick off a bunch of declarative rules out of the Portal.

Summary

Thinking outside of the box and using the Granfeldt PowerShell MA I was able to quickly consume a CSV file from an Exchange Inbox to kick off the provisioning process.

Follow Darren on Twitter @darrenjrobinson

Managing SharePoint Online (SPO) User Profiles with FIM/MIM 2016 and the Granfeldt PowerShell MA

Forefront / Microsoft Identity Manager does not come with an out-of-the-box management agent for managing SharePoint Online.

Whilst the DirSync/AADConnect solution will allow you to synchronise attributes from your On Premise Active Directory to AzureAD, SharePoint only leverages a handful of them. It then has its own set of attributes that it leverages. Many are similarly named to the standard Azure AD attributes but with the SPS- prefix.

For example, here is a list of SPO attributes and a couple of references to associated Azure AD attributes;

  • UserProfile_GUID
  • SID
  • SPS-PhoneticFirstName
  • SPS-PhoneticLastName
  • SPS-PhoneticDisplayName
  • SPS-JobTitle
  • SPS-Department
  • AboutMe
  • PersonalSpace
  • PictureURL
  • UserName
  • QuickLinks
  • WebSite
  • PublicSiteRedirect
  • SPS-Dotted-line
  • SPS-Peers
  • SPS-Responsibility
  • SPS-SipAddress
  • SPS-MySiteUpgrade
  • SPS-ProxyAddresses
  • SPS-HireDate
  • SPS-DisplayOrder
  • SPS-ClaimID
  • SPS-ClaimProviderID
  • SPS-ClaimProviderType
  • SPS-SavedAccountName
  • SPS-SavedSID
  • SPS-ResourceSID
  • SPS-ResourceAccountName
  • SPS-ObjectExists
  • SPS-MasterAccountName
  • SPS-PersonalSiteCapabilities
  • SPS-UserPrincipalName
  • SPS-O15FirstRunExperience
  • SPS-PersonalSiteInstantiationState
  • SPS-PersonalSiteFirstCreationTime
  • SPS-PersonalSiteLastCreationTime
  • SPS-PersonalSiteNumberOfRetries
  • SPS-PersonalSiteFirstCreationError
  • SPS-DistinguishedName
  • SPS-SourceObjectDN
  • SPS-FeedIdentifier
  • SPS-Location
  • Certifications
  • SPS-Skills
  • SPS-PastProjects
  • SPS-School
  • SPS-Birthday
  • SPS-Interests
  • SPS-StatusNotes
  • SPS-HashTags
  • SPS-PictureTimestamp
  • SPS-PicturePlaceholderState
  • SPS-PrivacyPeople
  • SPS-PrivacyActivity
  • SPS-PictureExchangeSyncState
  • SPS-TimeZone
  • SPS-EmailOptin
  • OfficeGraphEnabled
  • SPS-UserType
  • SPS-HideFromAddressLists
  • SPS-RecipientTypeDetails
  • DelveFlags
  • msOnline-ObjectId
  • SPS-PointPublishingUrl
  • SPS-TenantInstanceId

My customer has AADConnect in place that is synchronising their On Premise AD to Office 365. They also have a MIM 2016 instance that is managing user provisioning and lifecycle management. I’ll be using that MIM 2016 instance to manage SPO User Profile Attributes.

The remainder of this blog post describes the PS MA I’ve developed to manage the SPO attributes to allow their SPO Online Forms etc to leverage business and organisation user metadata.

Using the Granfeldt PowerShell Management Agent to manage SharePoint Online User Profiles

In this blog post I detail how you can synchronise user attributes from your On Premise Active Directory to an associated users SharePoint Online user profile utilising Søren Granfeldt’s extremely versatile PowerShell Management Agent. Provisioning and licensing of users for SPO is performed in parallel by the DirSync/AADConnect solution. This solution just provides attribute synchronisation to SPO User Profile attributes.

Overview

In this solution I’m managing the attributes that are pertinent to the customer. If you need an additional attribute or you have created custom attributes it is easy enough to extent.

Getting Started with the Granfeldt PowerShell Management Agent

First up, you can get it from here. Søren’s documentation is pretty good but does assume you have a working knowledge of FIM/MIM and this blog post is no different.

Three items I had to work out that I’ll save you the pain of are;

  • You must have a Password.ps1 file. Even though we’re not doing password management on this MA, the PS MA configuration requires a file for this field. The .ps1 doesn’t need to have any logic/script inside it. It just needs to be present
  • The credentials you give the MA to run this MA are the credentials for the account that has permissions to manage SharePoint Online User Profiles. More detail on that further below.
  • The path to the scripts in the PS MA Config must not contain spaces and be in old-skool 8.3 format. I’ve chosen to store my scripts in an appropriately named subdirectory under the MIM Extensions directory. Tip: from a command shell use dir /x to get the 8.3 directory format name. Mine looks like C:\PROGRA~1\MICROS~4\2010\SYNCHR~1\EXTENS~2\SPO

Managing SPO User Profiles

In order to use this working example there are a couple of items to note;

  • At the top of the Import and Export scripts you’ll need to enter your SPO Tenant Admin URL. If your tenant URL is ‘CORP.sharepoint.com’ then at the top of the scripts enter ‘CORP-admin.sharepoint.com’. The Import script will work with corp.sharepoint.com but the export won’t.
  • Give the account you’re using to connect to SPO via your MIM permissions to manage/update SPO User Profiles

Schema.ps1

As mentioned above I’m only syncing attributes pertinent to my customers’ requirements. That said I’ve selected a number of attributes that are potentials for future requirements.

Password Script (password.ps1)

Empty as described above

Import.ps1

A key part of the import script is connecting to SPO and accessing the full User Profile. In order to do this, you will need to install the SharePoint Online Client Components SDK. It’s available for download here https://www.microsoft.com/en-us/download/details.aspx?id=42038

The import script then imports two libraries that give us access to the SPO User Profiles.

Import-Module
‘C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\16\ISAPI\Microsoft.SharePoint.Client.UserProfiles.dll’

Import-Module
‘C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\16\ISAPI\Microsoft.SharePoint.Client.dll’

Import values for attributes defined in the schema.

Export.ps1

The business part of the MA. Basically enough to take attribute value changes from the MV to the SPO MA and export them to SPO. In the example script below I’m only exporting three attributes. Add as many as you need.

Wiring it all together

In order to wire the functionality together, I’m doing it just using the Sync Engine MA configuration as we’re relying on AADConnect to create the users in Office365, and we’re just flowing through attribute values.

Basically, create the PS MA, create your MA Run Profiles, import users and attributes from the PS MA, validate your joins and Export to update SPO attributes as per your flow rules.

Management Agent Configuration

As per the tips above, the format for the script paths must be without spaces etc. I’m using 8.3 format and I’m using the Office 365 account we gave permissions to manage user profiles in SPO earlier.

Password script must be specified but as we’re not doing password management it’s empty as detailed above.

If your schema.ps1 file is formatted correctly you can select your attributes.

I have a few join rules. In the pre-prod environment though I’m joining on WorkEmail => mail.

My import flow is just bringing back in users mobile numbers that users are able to modify in SPO. I’m exporting Title, Location and Department to SPO.

Summary

Using the Granfeldt PowerShell MA it was very easy to manage user SharePoint Online User Profile attributes.

Follow Darren on Twitter @darrenjrobinson
