Identifying Active Directory Users with Pwned Passwords using Microsoft/Forefront Identity Manager

Update: An element of this solution details checking passwords online (using the Have I Been Pwned API). Troy explains succinctly in his blog-post announcing the pwned passwords list why this is a bad idea. If you are looking to implement the concept I detail in this post then WE STRONGLY recommend using a local copy of the pwned password list.
THIS POST HERE details using a local SQL Database to hold the Pwned Passwords Datasets and the change to the Management Agent to query the SQL DB instead of the HIBP API.

Introduction

Last week (3 Aug 2017) Troy Hunt released a sizeable list of Pwned Passwords. 320 Million in fact. I encourage you strongly to have a read about the details here.

Troy also extended his HaveIBeenPwned API to include the ability to query as to whether a password has been pwned and is likely to be used in a brute force attack.

Microsoft provide a premium license feature in Azure Active Directory (Azure Active Directory Identity Protection) whereby leaked credential sets are checked and Admins alerted via reports. But what if you aren’t licensed for the Azure AD Premium Features, or you want something a little more customised and you have Microsoft/Forefront Identity Manager? That is what this post covers.

Overview

The following diagram looks a little more complicated than what it really is. The essence though is that password changes can come from a multitude of different scenarios. Using Microsoft’s Password Change Notification Service (PCNS) we can capture password changes and send them to Microsoft Identity Manager so that we can synchronise the password to other systems, or for this use case we can lookup to see if the users new password is on the pwned password list.

This post will cover creating the Pwned Password FIM/MIM Management Agent and flagging a boolean attribute in the MIM Service to indicate whether a users password is on the pwned password or not.

Pwned Password Overview
Password change and sync architecture

Prerequisites

There are a few components to this solution depicted above. You will need;

  • FIM/MIM Synchronisation Server
    • with an Active Directory Management Agent configured (most likely you will have a Projection Rule on this MA to get your users into the Metaverse)
    • not shown in the diagram above you will also need the MIM MA configured to sync users from the Metaverse to the MIM Service
  • FIM/MIM Service and Portal Server (can be on the same server as above)
  • Microsoft Password Change Notification Service (PCNS). This MS PFE PCNS implementation document covers it quite well and you will need;
    • the PCNS AD Schema Extension installed
    • the PCNS AD Password Filters installed on all your (writeable) Domain Controllers
    • PCNS configured to send password changes to your FIM/MIM Sync Server
  • Granfeldt PowerShell Management Agent (that we will use to check users passwords against the Have I Been Pwned pwned password API)
  • Lithnet Resource Management PowerShell Module
    • download it from here and install it on your FIM/MIM Server as the Pwned Password MA will use this module to populate the Pwned Password Status for users in the MIM Service
  • Windows Management Framework (PowerShell) 5.x

Getting Started with the Granfeldt PowerShell Management Agent

If you don’t already have it go get it from here. Søren’s documentation is pretty good but does assume you have a working knowledge of FIM/MIM and this blog post is no different.

Four items of note for this solution;

  • You must have an Export.ps1 file. Even though we’re not doing exports on this MA, the PS MA configuration requires a file for this field. The .ps1 doesn’t need to have any logic/script inside it. It just needs to be present
  • The credentials you give the MA to run this MA are the credentials for the account that has permissions to the On Premise Active Directory where we will be importing users from to join to our Metaverse so we can pass password changes to this Management Agent
  • The same account as above will also need to have permissions in the MIM Service as we will be using the account to update the new attribute we are going to create
  • The path to the scripts in the PS MA Config must not contain spaces and be in old-skool 8.3 format. I’ve chosen to store my scripts in an appropriately named subdirectory under the MIM Extensions directory. Tip: from a command shell use dir /x to get the 8.3 directory format name. Mine looks like C:\PROGRA~1\MICROS~4\2010\SYNCHR~1\EXTENS~2\PwnedPWD

With the Granfeldt PowerShell Management Agent downloaded from Codeplex and installed on your FIM/MIM Server we can create our Pwned Password Management Agent.

Creating the Pwned PowerShell Management Agent

On your FIM/MIM Sync Server create a new sub-directory under your Extensions Directory. eg. PwnedPWD in C:\Program Files\Microsoft Forefront Identity Manager\2010\Synchronization Service\Extensions then create a sub-directory under PwnedPWD named DebugC:\Program Files\Microsoft Forefront Identity Manager\2010\Synchronization Service\Extensions\PwnedPWD\Debug

Copy the following scripts (schema.ps1, import.ps1, export.ps1, password.ps1) and put them into the C:\Program Files\Microsoft Forefront Identity Manager\2010\Synchronization Service\Extensions\PwnedPWD directory

Schema.ps1

The following schema.ps1 script sets up the object class (user) and a handful of attributes from Active Diretory that will be useful for logic that we may implement in the future based on users password status.

Import.ps1

The import.ps1 script connects to Active Directory to import our AD users into the Pwned Password Management Agent so we can join to the Metaverse object already present for users on the Active Directory Management Agent. The user needs to be joined to the Metaverse on our new MA so they are addressable as a target for PCNS.

Export.ps1

As detailed earlier, we aren’t using an Export script in this solution.

Password.ps1

The Password script receives password changes as they occur from Active Directory and looks up the Have I Been Pwned API to see if the new password is present on the list or not and sets a boolean attribute for the pwned password status in the MIM Service.

On your FIM/MIM Sync Server from the Synchronisation Manager select Create Management Agent from the right hand side pane.  Select PowerShell from the list of Management Agents. Select Next.

create pwned passwords management agent
create pwned passwords management agent

Give your MA a Name and a Description. Select Next.

create pwned passwords management agent
create pwned passwords management agent

Provide the 8.1 style path to your Schema.ps1 script copied from the steps earlier. Provide an AD sAMAccountName and Password that also has permissions to the MIM Service as detailed in the Prerequisites. Select Next.

connectivity pwned passwords management agent
connectivity pwned passwords management agent

Provide the paths to the Import.ps1, Export.ps1 and Password.ps1 scripts copied in earlier. Select Next.

global parameters pwned passwords management agent
global parameters pwned passwords management agent

Select Next.

partitions and hierarchies pwned passwords management agent
partitions and hierarchies pwned passwords management agent

Select the user checkbox. Select Next.

object types pwned passwords management agent
object types pwned passwords management agent

Select all the attributes in the list. Select Next.

attributes pwned passwords management agent
attributes pwned passwords management agent

Select Next.

anchors pwned passwords management agent
anchors pwned passwords management agent

Select Next.

connector filter pwned passwords management agent
connector filter pwned passwords management agent

Create a Join Rule for your environment. eg.  sAMAccountName => person:Accountname  Select Next.

join and projection rule pwned passwords management agent
join and projection rule pwned passwords management agent

Create an import flow rule for user:pwdLastSet => person:pwdLastSet. Select Next.

attribute flow pwned passwords management agent
attribute flow pwned passwords management agent

Select Next.

deprovisioning pwned passwords management agent
deprovisioning pwned passwords management agent

Ensure that Enabled password management is selected, then select Finish.

Enabled password management pwned passwords management agent
Enabled password management pwned passwords management agent

With the Pwned Password MA created and configured we need to create at least a Stage (Full Import) and Full Sync Run Profiles and execute them to bring in the users from AD and join them to the Metaverse.

This should be something you’re already familiar with.

Run Profiles Pwned Passwords Management Agent
Run Profile pwned passwords MA

When running the Synchronisation we get the joins we expect. In my environment PwdLastSet was configured to sync to the MIM Service and hence the Outbound Sync to on the MIM Service MA.

Sync and join pwned passwords MA
MIM Synchronisation pwned passwords MA

MIM Service Configuration

In the MIM Service we will create a custom boolean attribute that will hold the pwned status of the users password.

Schema

Connect to your MIM Portal Server with Administrator privileges and select Schema Management from the right hand side menu.

create attribute pwned password
create attribute pwned password

Select All Attributes then select New

create attribute pwned password
create attribute pwned password

Provide an attribute name (System name) and a Display Name with a Data Type of Boolean. Provide a Description and select Finish

create attribute pwned password
create attribute pwned password

Select Submit

create attribute pwned password
create attribute pwned password

Search for User in Resource Types then select the User checkbox from the search results and select Binding then select New.

MIM Schema create binding for pwned password attribute
MIM Schema create binding for pwned password attribute

In the Resource Type box type User then click the validate field button (the one with the green tick). In the Attribute Type box type Pwned Password then click the validate field button (the one with the green tick). Select Finish

create binding for pwned password attribute
create binding for pwned password attribute

Select  Submit

create binding for pwned password attribute
create binding for pwned password attribute

Configure the Active Directory MA to send passwords to the Pwned Passwords MA

On your existing Active Directory Management Agent select Properties. Select Configure Directory Partitions then under Password Synchronization enable the checkbox Enable this partition as a password synchronization source. Select Targets and select your newly created Pwned Password MA. Select Ok then Ok again.

Pwned Password MA
Pwned Password MA

Testing the End to End Pwned Password Check

Now you should have configured;

  • PCNS including installation of the Active Directory filters
  • The existing Active Directory Management Agent as a Password Source
  • The existing Active Directory Management Agent to send password change events to the Pwned Password MA

Select a user in Active Directory Users and Computers, right click the user and select Reset Password.

Active Directory Users and Computers, right click the user and select Reset Password
Active Directory Users and Computers, right click the user and select Reset Password

I first provided a password I know is on the pwned list, Password1

 password I know is on the pwned list
password I know is on the pwned list
Password Changed
Password Changed

With PCNS Logging enabled on the MIM Sync Server I can see the password event come through.

PCNS Logging enabled on the MIM Sync Server
PCNS Logging enabled on the MIM Sync Server

Checking in the Pwned Password MA debug log we can see in the debug logging for the user we changed the password for and that when it was checked against Have I Been Pwned the password is flagged as pwned.

Note: If you implement the solution in a production environment obviously remove the password from being logged.

Pwned Password MA debug log
Pwned Password MA debug log

In the MIM Portal search for and locate the user the password we just changed the password for.

MIM Portal search for and locate the user
MIM Portal search for and locate the user

Select the user. Scroll to the bottom and select Advanced View. Select the Extended Attributes tab. Scroll down and we can see the Pwned Password shows as checked.

Pwned Password shows as checked
Pwned Password shows as checked

Now repeating the process with a password that isn’t in the Pwned Password list. After changing the password in Active Directory Users and Computers the password went through its sync path. The log shows the password isn’t in the list.

log shows the password isn't in the pwned password list
log shows the password isn’t in the pwned password list

And the MIM Portal shows the Boolean value for Pwned Password is now not selected.

Pwned Password is now not selected
Pwned Password is now not selected

Summary

Using PCNS and FIM/MIM we can check whether our Active Directory users are using passwords that aren’t in the Pwned Password list.

What we can then do if their password is in the Pwned Password list is a number of things based on what the security policy is and even what type of user it is. You’ll notice that I’ve included additional attributes in the MA that we can flow through the Metaverse and into the MIM Service that may help with some of those decisions (such as adminCount which indicates if the user is an Administrator).

Potentially for Admin users we could create a workflow in the MIM Service that forces their account to change password on next logon. For other users we could create a workflow that sends them a notification letting them know that they should change their password.

Either way, we now have visibility of the state of users passwords. Big thanks to Troy for adding Pwned Passwords to his Have I Been Pwned API.



Reiterating: An element of this solution details checking passwords online (using the Have I Been Pwned API). Troy explains succinctly in his blog-post announcing the pwned passwords list why this is a bad idea. If you are looking to implement the concept I detail in this post then WE STRONGLY recommend using a local copy of the pwned password list.
